EUROTEAM STRADA II Benutzerhandbuch Seite 119

= APPROVED
Figure 70
REPLACE WHEN WORN
Gates Carbon Drive™ Belts and Sprockets are
extremely durable and built to offer a long life, but
they do wear and tear over time. Periodically,
carefully inspect your belt and sprockets for
signs of deterioration:
This belt is in excellent condition.
Loss of blue color does NOT indicate wear.
Snubber not
standard on
all models.
Figure 71
Figure 73
= NO
Use Caution. Although clean of grease, belt drives
can still catch pants, skirts or loose clothing.
Installation of a belt guard is recommended.
Figure 72
118
