User Manual Overhead Projector reflecta cubus 251, 253 and 401, 403
SPECIFICATION AND TECHNICAL DATA
cubus
Lamp
Voltage
Two-lamp
changer
Safety switch
Working stage
Projection angle 360∘ rotation and tilting angle up to 60∘
Focal length
Light output
Packing
dimensions
Gross Weight
251
24V/250-300W Dual lamp
Is equipped with safety and reliable two-lamp changer device. For
working continuously make sure there are always two functional
lamps inserted.
Power supply will be shut off when the top cover is opened. Insure the
maintenance man's safety, unplug the mains cable additionally.
285mmx285mm
1-Element lens
f=285mm
2000 lumens
54x45x34,5cm
12.5kg
353
220V/240V~/50Hz
3-Element lens 1-Element lens
f=320mm f=285mm
2000 lumens 3000 lumens
54x45x34,5cm 54x45x34,5cm
13kg 13,5kg
401 403
36V/400W Dual lamp
3-Element lens
f=320mm
3000 lumens
54x45x34,5cm
14kg
