BREW MONK CONICAL FERMENTER Bedienungsanleitung Seite 3

Instruction Manual Brew Monk - EN
ASSEMBLY INSTRUCTIONS
Install the thermowell. Make sure the nut is screwed on properly. Install the black rubber. Insert the
thermometer.
Put the ball-valve into the provided hole on the conical bottom and tighten it with a M12 nut. It is located
at the front of the fermenter, on the conical part as shown. Tip: insert the rotating arms into the valve
inlet as shown, the racking arm direction can be adjusted by rotating the ball-valve during fermentation.
Seal the strainer valve with some PTFE tape (not included), screw the strainer valve onto strainer pipe as
shown. Tip: make sure the PTFE tape is sealed enough to prevent leakage.
Attach 3 detachable stands with M6 screws and M6 nuts.
3
