Hotkey and push-button reference sheet
Command
Select PC Channel
(Joint select PC, hub and audio
and mic port control if binding
enabled)
Select Audio and Mic Channel
Bind PC and Audio/Mic
Switching (default)
Unbind PC and Audio/Mic
Switching
Next lower PC Channel
(Joint select PC port and hub port
control if binding is enabled)
Next higher PC Channel
(Joint select PC port and hub port
control if binding is enabled) 3
Previous PC Channel
Define Hotkey Preceeding
Sequence
Console Mouse and/or
Keyboard Reset
Autoscan
Autoscan with Programmable
Delay Time
Stop Autoscan
USA Notification
