DESCRIPTION

1.1

PURPOSE

You may use this product for cutting purposes:
• cutting all types of wood
• cutting plastic
• cutting metals
1.2

OVERVIEW

Figure 1.
Trigger
1
Tube
2
Angle Adjustment
3
Trigger
Footplate
4
Blade Orbit Selector
5
Lever
1.3

PACKING LIST

1 Jig saw
2 Dust tube
3 Edge guide
4 Wood blade
5 Steel blade
2

SAFETY

Make sure that you do/obey all safety instructions.
Refer to Safety Manual.
3

INSTALLATION

3.1

UNPACK THE MACHINE

Make sure that you correctly assemble the machine before
use.
• If the parts are damaged, do not use the machine.
• If you do not have all the parts, do not operate the
machine.
• If the parts are damaged or missing, speak to the service
center.
1. Open the package.
2. Read the documentation in the box.
3. Remove all the unassembled parts from the box.
Blade
6
Edge Guide Knobs
7
Edge Guide
8
Finger Guard
9
10 Lock-off Button
6 Footplate
7 Manual ( operation
manual, safety
instruction manual,
figure sheet )
WARNING
WARNING
WARNING
English
4. Remove the machine from the box.
5. Discard the box and package in compliance with local
regulations.
3.2

INSTALL THE BATTERY PACK

Figure 2.
• If the battery pack or charger is damaged, replace the
battery pack or the charger.
• Stop the machine and wait until the motor stops before
you install or remove the battery pack.
• Read, know, and do the instructions in the battery and
charger manual.
1. Align the lift ribs on the battery pack with the grooves in
the battery compartment.
2. Push the battery pack into the battery compartment until
the battery pack locks into place.
3. When you hear a click, the battery pack is installed.
3.3

REMOVE THE BATTERY PACK

Figure 2.
1. Push and hold the battery release button.
2. Remove the battery pack from the machine.
3.4

INSTALL THE BLADE

Figure 3.
1. Remove battery pack.
2. Rotate the blade clamp lock counterclockwise. Hold the
lock in the open position.
3. Insert saw blade between blade clamp and saw bar.
4. Close blade clamp lock.
5. Reinstall the battery pack.
3.5

REMOVE THE BLADE

Figure 3.
1. Remove battery pack.
2. Rotate the blade clamp lock counterclockwise. Hold the
lock in the open position.
3. Remove the saw blade.
3.6

INSTALL THE EDGE GUIDE

Figure 4.
Put the edge guide through the two slots in the base of the
machine.
Adjust to the necessary width and lock in place with the edge
guide screw.
4
WARNING
