3.4

Hydraulic plan

3.4.1 Without wheel free lift
0.1 450CL01123 OIL CONTAINER
0.2 980201 OIL FILTER
0.3 992658 MOTOR
0.4 980340 MECHANICAL PUMP
0.5 980098 OIL DIPSTICK WITH VENTILATION
0.7 440H01160 BLOCK
OPI_COMBI LIFT 4.50/4.65 S PLUS AMS - HYMAX II 4500/4650 S PLUS AMS_V1.1_DE-EN-FR-ES-IT
V2
0 .9
SRV
0 .7
0 .1
A
0.12
0.11
V1
0.7mm
RV1
0.10
DBV
0 .8
T P
0 .5
0 .3
0 .4
M
0 .2
0.8 155211
0.9 600161
0.10 130053
0.11 980853
0.12 982557
Me
PRESSURE RELIEF VALVE
LOWERING BRAKE
CHECK VALVE
DOUBLE SEATED VALVE
SEAT VALVE
V 0 0
Nr. V
169
