Inhaltsverzeichnis - HAWA Frontslide 60 A Symmetric 2 Planungs- Und Montageanleitung

Hawa Frontslide 60 A Symmetric 2 100 A Symmetric 2 140 A Symmetric 2
1 Table of contents
Contents
2 Product information
3 Abbreviations, symbols
4 Overviews
5 Planning
6 Calculation
7 Pre-assembly
8 Assembly
9 Disassembling
10 Optional
6/40
4.1 Overview: Hawa Frontslide 60 A Symmetric 2, 100 A Symmetric 2 and 140 A Symmetric 2
4.2 Overview: position numbers
5.1 Planning: Hawa Frontslide 60 A Symmetric 2
5.2 Planning: Hawa Frontslide 60 A Symmetric 2
5.3 Planning: Angled profile support for Hawa Frontslide 60 A Symmetric 2
5.4 Planning: Angled profile support with spacer profile for Hawa Frontslide 60 A Symmetric 2
5.5 Planning: Hawa Frontslide 100 A Symmetric 2
5.6 Planning: Hawa Frontslide 140 A Symmetric 2
5.7 Planning: Guide situations
6.1 Calculation: Sliding shutter width, top track and bottom guide channel
6.2 Calculation: Toothed belt length
6.3 Calculation: Suspension points
6.4 Calculation: Drill holes, sliding shutter
6.5 Calculation: Drill holes, bottom sliding shutter guide
7.1 Pre-assembly: Sliding shutters
8.1 Assembly: Top track
8.2 Assembly: Bottom guide channel
8.3 Assembly: Sliding shutter
8.4 Assembly: Deflection roller
8.5 Assembly: Toothed belt
8.6 Assembly: Driver
8.7 Assembly: track stop
8.8 Assembly: Cover
9.1 Disassembling: Toothed belt lock, driver
10.1 Optional: Locking and securing options Hawa Frontslide 60 A Symmetric 2
10.2 Optional: Assembly using hammer head bolts type 28/15 provided by the customer
10.3 Optional: Cover cap
10.4 Optional: Connecting pins
Page
7
8
9
10
11
12
13
14
15
16
17
18
18
19
20
22
23
25
26
27
30
31
32
33
34
35
36
37
38
38
