• sicheren • vorteilhaften Gebrauch des IMPERIAL BAS 1. Es wird voraus- gesetzt, dass der Bediener allgemeine Kenntnis- se im Umgang mit Unterhaltungselektronik hat und den Inhalt dieser Anleitung vor der ersten Inbetriebnahme zur Kenntnis genommen hat. 2. Sicherheitshinweise Auch wenn ein Lautsprecher an sich nichts ge- fährliches ist, sollen Sie mögliche Risiken beim...
Temperaturen und Feuchtigkeit können den eingebauten Akku beschädigen und einen Brand oder eine Explosion auslösen. 3. Lieferumfang Bitte überprüfen Sie den Lieferumfang des IM- PERIAL BAS 1 vor der ersten Inbetriebnahme auf Vollständigkeit. Im Lieferumfang enthalten ist: Downloaded from www.Manualslib.com...
• IMPERIAL BAS 1 (je nach Ausführung in weiß oder schwarz) • Ladekabel (USB auf Mikro USB) • 3.5mm Anschlusskabel • Bedienungsanleitung • Garantiekarte 3.1. Abbildungen 1. Ein-/Ausschalter (Position links aus, Position rechts ein) 2. Status LED rot = lädt, grün =...
Seite 6
4. Mikro USB Buchse Buchse zum Laden des integrierten Akkus über das Ladekabel (im Lieferumfang enthalten) 5. Cinch Buchse Für den Betrieb mit externen Geräten über Kabel (AUX Modus) 6. (M) Taste Zum Wechsel zwi- schen Bluetooth-, AUX- und TF Modus 7.
Im TF- und Bluetoothmodus zum nächsten Titel springen, Wiedergabelautstärke lauter. 4. Inbetriebnahme Vor der ersten Inbetriebnahme empfehlen wir, den BAS 1 mit Hilfe des im Lieferumfang ent- haltene USB Ladekabels vollständig aufzuladen. Hierzu gehen Sie wie folgt vor: • Verbinden Sie das Ladekabel mit der Mikro USB Buchse des IMPERIAL BAS 1.
4.1. Bluetooth Modus Nachdem Sie den BAS 1 wie unter 4. beschrie- ben aufgeladen haben, können Sie den Laut- sprecher verwenden. Hier stehen Ihnen 3 Mög- lichkeiten zur Verfügung, die Sie durch Drücken der (M) Taste (siehe Abb. 6) einstellen können.
• Nun kann der BAS 1 mit dem Bluetoothge- rät verwendet werden. Hinweis: das Pairing muss i.d.R. nur einmal durchgeführt werden. Möchten Sie nach einer Pause die Verbindung erneut herstellen, sollte dies automatisch erfolgen, sobald Sie den BAS 1 einschalten. Möchten Sie ein neues Bluetooth Gerät mit dem BAS 1 verbinden, trennen Sie...
Sie die Lautstärke der Wiedergabe. 4.1.3. Telefonmodus Sofern Sie ein Smartphone über Bluetooth mit dem Lautsprecher gekoppelt haben, steht Ihnen auch der Telefonmodus des BAS 1 zur Verfü- gung. Diesen nutzen Sie wie folgt: • Erhalten Sie einen Anruf auf Ihrem Smart- phone, wird die Musikwiedergabe unter- brochen und ein Klingelton signalisiert über...
Sie die (-) Taste. 4.2. TF Modus Dank des integrierten Micro SD Kartenlesers kann der BAS 1 auch Musikdateien von Spei- cherkarten wiedergeben. Um diesen Modus aufzurufen, gehen Sie wie folgt vor: • Stecken Sie eine Micro SD Karte in den Kartenleser (siehe Abb.
Schalten Sie das Wiedergabegerät ein und beginnen Sie mit der Musikwiedergabe. • Betätigen Sie die (M) Taste (siehe Abb. 6) des BAS 1, um auf den AUX Modus zu schalten. Die Status LED leuchtet orange. • Über die (> ƖƖ) Taste des BAS 1 können Sie die Wiedergabe pausieren bzw.
5. Fehlersuchhilfe Problem Ursache Lösung BAS 1 lässt Akku leer Akku über sich nicht USB Ladeka- einschalten bel aufladen Keine Musik- 1. BAS 1 1. Durch wiedergabe befindet sich Drücken der hörbar im falschen (M) Taste Modus den Modus Wechseln 2.
Problem Ursache Lösung Bluetooth- 1. BAS 1 1. Modus verbindung im falschen über (M) Tas- kann nicht Modus te wechseln hergestellt 2. Bluetooth 2. Bluetooth werden nicht einge- einschalten schaltet und verbin- Bluetooth- Gerät mit Passwort verbindung Bluetooth- eingeben verlangt version <...
Ladespannung: 5V DC über USB Kabel 3.5mm Cinch Audio Eingang 1999/5/EG-konform 7. Technische Hotline Sollte Ihr BAS 1 einmal nicht richtig funktio- nieren, muss nicht gleich ein Defekt vorliegen. Gerne helfen wir Ihnen unter 02676/9520101 weiter. Alternativ kontaktieren Sie uns per Mail über service@telestar.de oder per Fax über die...
Seite 16
Table of contents 1. Preface 2. Your safety is important! 3. Scope of delivery 3.1. Images 4. Getting started 4.1. Bluetooth mode 4.1.1. Establish connection 4.1.2. Music playback 4.1.3. Phone mode 4.2. TF mode 4.3. AUX mode 5. Troubleshooting 6. Technical data 7.
1. Preface Thank you for choosing this high-quality product. This manual is kept brief because we know you want to start using the product in stead of rea- ding this manual. However for the best listening experience you need some basic information on the usage of the product.
3. Scope of delivery Please check the scope of delivery before using the BAS 1 for the first time. The delivery contents includes following items: • IMPERIAL BAS 1 (white or black edition) •...
3.1. Images 1. On-off switch (Position left off, positi- on right on) 2. Status LED red = charging, green = charged, blue (flashing) = Bluetooth mode connection search, blue (per- manent) = Bluetooth mode connected, orange = TF mode & AUX mode 3.
Seite 20
4. Micro USB port Charging port for in- ternal battery via char- ging cable (included) 5. Cinch port For connection of external devices via cable (included), ope- ration in AUX mode 6. (M) button To switch between Bluetooth, TF and AUX mode 7.
Next track (Bluetooth & TF mode), increase playback volume 4. Getting started Before getting started, we recommend to fully charge the IMPERIAL BAS 1 by using the USB charging cable. Please follow the procedure: • Connect the charging cable to the BAS 1‘s micro USB port.
4.1. Bluetooth mode After charging the BAS 1 according to point 4, the speaker system is ready to use. The IM- PERIAL BAS 1 may be used in three different modes that can be selected by pushing the (M) button (see image 6).
If you want to reconnect the device after a pause, it will set up automatically as soon as you switch on the BAS 1. If you want to con- nect a new device via Bluetooth, cut the estab- lished connection by pushing and holding the (>...
4.1.3. Phone mode If you have paired a smart phone to the BAS 1 via Bluetooth, you may also use the speakers‘ phone mode of the speaker. The phone mode may be operated as follows: • When receiving an incoming call on your...
Bluetooth operation, just push the (M) button (see image 6). 4.3. AUX mode Via AUX mode, the BAS 1 may be used to play back music from devices to be connected with a 3.5mm audio cable (included). The AUX mode may be operated as follows: •...
Seite 26
• Turn on the BAS 1 by putting the slide switch (see image 1) to „on“ position. • Turn on the playback device and com- mence the music playback. • Push the (M) button (see image. 6) to set the BAS 1 to AUX mode. The status LED will switch to orange.
Problem Cause Solution BAS 1 may Battery Reload not be swit- empty battery ched on No music 1. BAS 1 in 1. Change playback wrong mode mode with audible (M) button 2. Switch 2. Playback on playback device swit- device ched off 3.
Problem Cause Solution Bluetooth 1. BAS 1 in 1. Change connection wrong mode mode with failure (M) button 2. Bluetooth deactivated 2. Switch on Bluetooth and connect Bluetooth Bluetooth Enter connection version on password requires device < BT (standard: password „0000“)
3.5mm Cinch Audio In 1999/5/EG-conform 7. Technical support If your BAS 1 doesn‘t work properly, this doesn‘t necessarily mean that the item is broken. Our technical support will try to solve your problem. Please feel free to contact us via email over ser- vice @telestar.de.
