Upgrade SCI-FOV Montageanleitung Seite 8

Installation of loudspeaker in the front door
Step 7
Installation of the woofer
The serial loudspeaker is fastened with 4 rivets.
Drill the rivets carefully out with a 5 mm bit and drill
machine or cordless screwdriver.
Attention!
After removing the speaker very carefully
remove possible residue from the door.
Now fasten the new loudspeaker with the included
rivets. Plug the connector of the speaker cable back
in the speaker.
Step 8
Remount the door paneling in reverse order.
Attention!
Do not forget to reconnect all cable plugs and to correctly replace the door
opening cable.
