Tools

The following tools are required and should be available:
Screw driver for Torx – size TX 30
or screw driver or small ratchet wrench with a bit head and bit size TX 30
Screw driver for slot screw – size about 5mm
or tire lever
Accumulator screw machine or drill machine
5 mm drill bit
Electrical pliers
Rivet gun
Downloaded from www.Manualslib.com
11
manuals search engine

Installation of loudspeaker in the front door

Step 1
Driver side & Passenger side: Carefully pry the grip dish out of the grip in the door paneling.
Pull the grip dish toward yourself. Be careful not to tilt the dish.
Step 2
Driver and passenger sides. You will now
see 3 screws Torx 30. Loosen them.
The next illustration shows the points where the door paneling is clipped on the back side.
Step 3
Another screw is locatet at the lower side of
the door paneling. Loose it too.
