Connection Diagram

CONNECTION DIAGRAM
Microphone
or Line
Outputs Inputs
R L
R -
USB 2.0
Stereo
Hi Z / Line
L L -
- Mic Line Mic
Computer
Powered Speakers
1/4" male to 1/4" male
(unbalanced)
IMPORTANT: Use only a USB 2.0 certified Hi-Speed cable (like the one
supplied) for the USB connection. Using a USB 1.1 cable may cause erractic
behavior and degraded performance.
