2.3

Functions

The TechniSat PowerLine Webcast 2 has three control lights (LEDs). Furthermore, the
device is equipped with an integrated socket, a network connection and an encryption
button.
integrated power socket
control lamp
network connection
2.3.1

Control lights (LEDs)

PWR Off
On
It fl ashes
ETH Off
On
It fl ashes
Data Off
On
It fl ashes
encoding button
the device is turned off
the device is turned on
the device is in the low consumption mode
no LAN connection
existing LAN connection
data transmission through LAN interface
no connection to Powerline network
existing Powerline connection
data transmission through Powerline network
