TRANSMITTER FUNCTIONS
EXP adjustment
EXP is used to adjust the central servo travel value for each channel (Chl or Ch2 )
EXP range
+ -
0-( ) 100% for each channel
Adjustment buttons-use "+" or "-" keys for changing values
EXP Steering Adjustment
1. Press the "SEL" key to select the desired function. EXP (see drawing above)
2. Select channel 1 using the "CH" key.
3. Use the "+" and "-" keys to adjust the EXP value.
4. After finishing adjustments , press the "SEL" key to return to the initial screen.
Steering EXP will work in both left and right directions.
EXP Steering Adjustment
1. Press the "SEL" key to select the desired function. EXP (see drawing above)
2. Select channel 2 using the "CH" key.
3. Use the "+" and "-" keys to adjust the EXP value.
4. After finishing adjustments , press the "SEL" key to return to the initial screen.
Throttle EXP only works in forward directions.
Negative Steering EXP
Faster servo movement
in center, slower after
EXP percentage
B 100
0
L 100
Downloaded from www.Manualslib.com
EXP
Positive Steering EXP
Slower servo movement
in center, fasrer after
EXP percentage
B 100
L-100
0
R-100
L 100
0
Wheel Movement Wheel Movement
EXP Steering
manuals search engine
EXP
Negative Throttle EXP
Faster servo movement
in center, slower after
EXP percentage
R 100
L-100 F-100
0
R-100
F 100
0
Trigger movement
10
Positive Throtte EXP
Slower servo movement
in center, fasrer after
EXP percentage
B 100
F-100
0
0
F 100
0
Trigger movement
EXP Throttle
