CHARLY OPERATING INSTRUCTIONS

2. Operation

7
6
CH2002B2
Fig. 2: CHARLY
1) Headlights
2) Locking bow
3) Steering rod mount
4) Battery compartment lid
5) Seat support mount
6) Baggage carrier
7) Hook for security clamp
8) Seat pillar adjustment
1
2
Fig. 4 Controls
1) Turning handle for speed
regulator
2) Front wheel brake lever
3) Headlights
Downloaded from www.Manualslib.com
1
2
8
5
4
3
3
manuals search engine
Fig. 3 Baggage carrier shown
with folding baggage basket
(available as an accessory)
5
4
CH2002B4
4) Rear wheel brake lever
5) Speedometer
