Mounting of CASING SP - LG XE4F to wall
Please ensure power
cable is available at
installation site!
Without power at installation site
complete installation cannot be
performed.
Please ensure the following:
UV resistant and insulated cable
Cable area of min 1,5 mm
Connected to external power switch with
10A fuse
If cable is over 3m, additional grounding
is required.
1
Select orientation of display
Mark holes position on wall
A2(1x)
Landscape
Top (for landscape)
CASING SP - LG XE4F 7
Portrait
