Basic Setup - Nayar Systems Nearkey Handbuch

3.3. Basic setup

As to setup Nearkey, place yourself close to the device. If you are already a Nearkey user, open the app
and read from to point 4.
1. Start the application and enter an accessible email at the time of configuration.
2. Nearkey will send an email to the address entered to verify the user's identity. Check the email
inbox and spam.
3. Press the enter button that will appear in the email, it will redirect you to the Nearkey
application.
4. Activate the Bluetooth connection.
5. Press the configuration button that will show the application. If the Nearkey app does not
display any devices, make sure of the following:
You are at a distance where the Bluetooth of the mobile can detect the device.
•
Nearkey has not been configured previously and you do not have access permissions, in
•
this case the green power LED will be on. Consider reading section 8. Reset the device.
Nearkey has power, if the green power led is not lit, we recommend to read section 3.1.
•
Device installation.
6. Introduce a name that allows the logical association to the facilities.
7. Specify the time zone where the device will be installed.
8. Specify a name for Actuator 1, this will appear in the app button.
9. Modify the characteristics of Actuator 1 depending on the needs of the door. You can choose
between the following modes:
Pulse, punctual activation of the relay, is the most common option of activation (door
•
motors, automatic entryphones, gates or electronic buttons among others). When the app
button is pressed, the relay will go from the NC position to NO for the seconds specified in
the Duration section.
Switch, static on/off mode. When the app button is pressed, the relay will change from
•
the NC position to NO permanently until the button is pressed again.
10. Check the functioning of Nearkey.
If pressing the app button it generates a drive in the installation (the door opens, the key is
•
activated, etc.), the configuration has been carried out correctly.
8
