Technical parameters
Supply terminals:
Supply voltage:
Consumption:
Supply voltage:
Consumption:
Supply voltage tolerance:
Real time back-up:
Summer/winter time:
Output:
Number of contacts
- SHT-1, SHT-3:
- SHT-1/2, SHT-3/2:
Rated current:
Switching capacity:
Peak current:
Switching voltage:
Min. switching capacity DC:
Mechanical life:
Electrical life (AC1):
Time circuit
Real time back-up when de-
-energi.:
Accuracy:
Minimum interval:
Data stored for:
A1 - A2
AC/DC 12-240 V (AC 50-60 Hz)
AC 0.5 - 2 VA / DC 0.4 - 2 W
AC 230V / 50 - 60 Hz
AC max. 14 VA / 2 W
-15 %; +10 %
yes
automatic
1 x changeover (AgSnO
)
2
2 x changeover (AgSnO
)
2
16 A / AC1
4000 VA / AC1, 384 W / DC
30 A / <3s
250 V AC1 / 24 V DC
500 mW
7
> 3x10
5
> 0.7x10
up to 3 years
max. ±1s/ day at 23°C
1 min.
min. 10 years
Cyclic output:
Pulse output:
Program circuit
Number of memory places:
Program (SHT-1; SHT-1/2):
Program(SHT-3, SHT-3/2):
Data readout:
Other information
Operating temperature:
Storage temperature:
Electrical strength:
Operating position:
Mounting:
Protection degree:
Overvoltage category:
Pollution degree:
2
Max. cable size (mm
):
Dimensions:
Weight
- SHT-1, SHT-3:
- SHT-1/2, SHT-3/2:
Standards:
- 5 -
1-99s
1-99s
100
daily, weekly
daily, weekly, monthly , yearly
(up to year 2095)
LCD display, with back light
-20.. +55 °C
-30.. +70 °C
4 kV (supply - output)
any
DIN rail EN 60715
IP10 clips, IP40 from front panel
III.
2
solid wire max. 2x 2.5 or 1x 4
with sleeve max. 1x 2.5 or 2x 1.5
90 x 35.6 x 64 mm
(UNI)-130 g, (230)-110 g
(UNI)-143 g, (230)-125 g
EN 61812-1, EN 61010-1
E
N E
N
