Parts and Features
Lid
Seals chamber
during vacuum
process.
BACK OF UNIT
OIL LEVEL
OIL INDICATOR
Indicates the level of oil in pump.
Level must be between the middle
holes as indicated.
Oil Fill Cap
Open to fill with oil.
OIL LEVEL
Oil Drain
Lid Gasket
Circuit Breaker
Cord Inlet
Technical Services
For assistance or replacement parts, call or e-mail
Technical Services:
866-285-1087 or
910-693-4277
commercial.support@hamiltonbeach.com
www.hamiltonbeachcommercial.com
Seal Pad
Creates counterpressure
on sealing bar.
Vacuum Chamber
Contents are placed into
chamber with opening of
vacuum-sealing pouch
positioned over seal bar.
Seal Bar
Seals vacuum-
sealing pouch.
Lid Retainer
Holds lid
closed when
unit is not
in use.
Control Panel
Selects and programs
functions.
ADDITIONAL PARTS
• Filler Plate
• Oil (Lubriplate Vacuum
Pump Oil Light - L0944
recommended)
• Plastic Bottle With Spout
• Phillips-Head Screwdriver
• Wrench
• Heater Tape
• Extra Heater
