Abit Guru Clock Anleitung Seite 4

L C D S c r e
L C D S c r e
CPU Speed: This section displays the readings of CPU speed.
• [Turbo], [Normal], [Quiet], [AutoDrive], [Default], [User1], [User2], and [User3]: These options
are the level you choose for OC Guru.
• [VGA]: This icon appears only when having ABIT's vGuru VGA card installed and its vGuru
function enabled.
Frequency/Voltage: This section displays the frequency or voltage readings detected from the
following items on motherboard:
• [CPU]: Central Processing Unit.
• [DDR]: DDR memory modules.
• [AGP]: AGP slot.
• [PCIE]: PCI Express slot.
• [FM]: (Function reserved)
• [CH]: (Function reserved)
• [VRAM]: Memory modules on ABIT's VGA card (Available for voltage reading only)
Room Temperature/Debug Code: This section displays the temperature readings detected from
Guru Clock.
• [Debug]: This icon lights up during the system starting up. The AWARD POST CODE will be
displayed at this moment. Any abnormal hardware configuration detected will halt the system and
display the error code on LCD screen. This icon lights off after entering operating system.
• [Room Temp]: This icon lights up when displaying the room temperature readings detected from the
thermal sensor located at Guru Clock. (As long as the system power supply is connected with AC
power source, this readings will be kept on displaying even after system power-off.)
Present Time: This section displays your preset time in 12-hour or 24-hour format. (As long as the
system power supply is connected with AC power source, this readings will be kept on displaying even
after system power-off.)
4
