INTENDED USE
The device is used for precise setting of horizontal and vertical lines.
Observe the following instructions when working for the best device operation. Use other than described below is not allowed
and may cause damage to the product.
Parameter
Self-levelling accuracy
Self-levelling range
Range
Operation time
Operating temperature
Storage temperature
Stand thread
Laser class
Laser wavelength
Laser power
Battery type
Dimensions
Weight
EXPLANATION OF USED SYMBOLS
1
1. Caution, laser radiation!
2. Caution, laser radiation – do not look in the laser beam
3. Read the instruction manual, observe warnings and safety conditions therein.
4. Segregated waste collection
DESCRIPTION OF DRAWING PAGES
Below enumeration refers to the device elements depicted on the drawing pages of this manual:
1. Switch
2. Operation indicator diode
3. Function change button
4. Stand thread
5. Battery lid
* Differences may appear between the product and drawing
MEANING OF SYMBOLS
WARNING
EQUIPMENT AND ACCESSORIES
1. Stand
2. Case
Battery replacement
• In order to unlock the battery lid (5), shift the lid gently in the direction shown by the arrow.
• Insert 2 new AA batteries, observe correct polarity.
• Close the battery lid, then shift it in direction opposite to the arrow.
USE OF MAGNETIC HOLDER
• In order to attach the cross line laser to the clamp holder, drive the threaded pin (1) into stand thread in the laser base.
• Ball adapter (2) allows to set the laser in any position from 0 to 90°.
• The wheel (3) allows to lock the laser in position.
• The clamp (4) allows to attach the holder to a surface.
Cross Line Laser 75-106
2 3
Value
± 0.5 mm/m
3,5°
15 m
up to 5 hours
+5°C – 35°C
-20°C – 70°C
¼ "
2
520 - 550 nm
< 1 mW
2 AA 1.5 V batteries
70 x 79 x 47 mm
180 g
4
