4. Operation:
Signal strength
100%-80%
70%
60%
50%-40%
28 / 116
1. Go to the locking device whose WaveNet accessib-
ility you want to test. In the process, close all doors
between the base station and the locking device to
be tested.
2. Set the Sig/Noise toggle switch to the Sig position
(signal measurement).
3. Hold the handset with its arm extended next to the
LockNode locking device.
4. Press the Activate button.
9 Signal strength is measured and displayed (see
table).
Data packet transmission is measured and
9
displayed (see table).
5. Repeat the signal strength measurement twice.
6. Set the Sig/Noise toggle switch to Noise (interfer-
ence signal measurement).
7. Hold the handset with its arm extended next to the
LockNode locking device.
8. Press the Activate button.
Interference signal strength is measured and
9
displayed (see table).
Optimal
Sufficient
Sufficient
Sufficient
WaveNet-Funktester
Connection can
be used (3060)
Yes
Yes
Yes
Yes
Connection can
be used
(SmartIntego)
Yes
Yes
No
No
