WaveNet-Funktester
Preparation
Measurement
EN
NOTE
Falsification due to changed base station location
A changed location of the base station falsifies all
measurement results obtained so far.
Do not change the location of the base station until

the measurements have been completed.
Base station and handset or accessories
ü
undamaged.
Handset battery full (see
ü
replacement [
1. Screw the antenna onto the base station.
2. Set up the base station at the planned location of
the router node.
3. Align the base station so that the antenna is ver-
tical.
4. Connect the base station to the power supply.
9 The green LED inside the base station flashes.
5. Insert the battery into the mobile station.
6. Switch on the mobile device with the on/off toggle
switch.
All LEDs light up temporarily.
9
9 Ready LED lights temporarily.
Ready LED flashes.
9
9 BAMO ready for operation.
If the error LED lights up permanently, there is a
hardware defect.
ü BAMO ready for operation.
Battery test and battery
31]
).
}
4. Operation:
