Shada LED's light Basic Bedienungsanleitung

LED's light Basic
Art Nr.
Power (W):
Input voltage (V AC):
Battery runtime:
Luminous fl ux (lm):
Lumen/W
Equivalent Light output(W):
Color temperature (K):
Color description
Lifespan(h):
Beam angle:
Warm up-time (95%):
Dimensions lamp(LxWxH mm):
Dimensions Rack(LxWxH mm): 208 x 160 x 240
Colour rendering index (CRI):
Energy class:
Battery: Li-ion / 3.7V / 2.200mAh / 8.14Wh
LED type: 2835 SMD (28x)
Protection class IP:
Dimmable
Cable type:
Battery charging:
Battery lifetime: max 500 charging cycles
Working temperature (T °C): -20°C ≤T ≤40°C
Housing: Aluminium, power coated
Packaging contents
1x LED luminaire
1x Manual
1x Rack
1x USB Charging cable
General safety instructions
Please read the operating instructions for the LED luminaire before use. The
operating instructions are part of the product. They contain important notes
on start-up and handling of the device. Always keep the enclosed operating
instructions so as to be able to look up information. They must be enclosed
when passing the device on to third parties.
Safety precautions
The user must observe the safety notes and warnings in order to maintain
this status and to ensure safe operation. Please read the operating
instructions before start up.
Never attempt to open the device, the LED luminaire cannot be repaired;
this part must be immediately disposed in case of a defect. Ensure
install in reach of children or animals.
Any other use of the device than described can damage the product or
endanger the user due to e. g. short-circuits, fi re or an electric shock. The
entire product may not be modifi ed or adapted.
These safety notes must be observed in all cases! Any
warranty claim is void in the case of damages caused by
non-observance of these operating instructions. We are
not liable for consequential damages or for damages to
property or persons caused by non-observance of the
safety notes and improper operation of the device.
Safe operation is not possible anymore, if:
- the LED luminaire has visible damages,
- the LED luminaire does not work anymore
Notes on Disposal
Old units, marked with the symbol as illustra-
ted, may not be disposed of in the household
rubbish.
You must take them to a collection point for
old units (enquire at your local authority) or
the dealer from whom you bought them. These agencies will
ensure environmentally friendly disposal.
300121
10
5V
1.5h
700
70
70
6.000
Cold white
20.000
10.000x
120°
<2s
133 x 24 x 100
Ra>80
A
IP54
No
1 m, USB - DC
2.5h
Safety notes
LED-lights are extremely bright. Under no circumstances
look into the light beam of the LED
lights, as this may cause permanent damage to
your eyes.
*If the glass is broken, it has to be replaced with a new
original protective glass before further use.
**FIRE HAZARD! Fit the light so that it is at least 1 m away
from the material to be illuminated. Excessive heat can
RISK OF INJURY FROM BURNS! Ensure the light has been
switched off and allowed to cool before you touch it.
Care and warranty
Before cleaning the unit, disconnect it if necessary from other
components; do not use aggressive cleaning agents.
The unit has been carefully checked for defects. If nevertheless
you do have cause for complaint, please go back to the retailer
where you have bought the product together with your proof
We are not liable for damage arising from incorrect handling,
improper use or normal wear and tear. We reserve the right to
make technical modifi cations.
Visit us online at www.eh-services.ch for more information
about our products and our company.
Installation and Operating Manual
Safety Class III
CE declaration
This product is according next directives:
LVD 2014/35/EU
EMC 2014/30/EU
RoHS 2011/65/EU
*
**
www.shada.nl • Molenmakershoek 28
NL-7328 JK Apeldoorn, The Netherlands
WEEE: NL: 3505,
DE: 37281017,
AT: 40133, ES: 7020
