Connection diagram for motor 3MJ 230
Single circuit
A single motor with one switch
A C
N
B
P
L N
Motor Wall switch
A B
Group circuit
Multiple motors (also in tandem operation) with one or multiple switches without or with signal lamp
(signal lamp goes out when all domes are closed)
The potential free contact for the OPEN indication opens when the dome is closed.
The number of motors is limited by the maximum load capacity of the switches (up to 10 motors).
A
B
P P
L
Motor Wall switch
A B
Nominal voltage
Power consumption
Power
Stroke
Lifting speed
Pressure force
Tractive force
Locking force
Protection
10 VELUX
®
A single motor with multiple switches
B
P
Potential free
C
C A
N
N
Potential free
C
230 V a.c. / 50 Hz Protection class
0.17 A Temperature range
Duty cycle
40 VA
Approx. 300 mm Housing
Approx. 6 mm/s Housing colour
500 N Housing dimensions (L x W x D)
Weight
200 N
3500 N Connection cable
IP54 Cable cross section
C
A
N
P P
L N
C A
N
A single motor with for instance two
switches and a signal lamp
OPEN/CLOSED indication via signal lamp (goes
out when the dome is closed).
A
B
P
L
C
N
2
-15 °C to +50 °C
30 % (3 min per 10 min)
Plastic
RAL 7035
450 x 42 x 90 mm
Approx. 1.5 kg
Approx. 1.8 m
5 x 0.75 mm
2
C
N
P
N
