COVER DISASSEMBLY
ENERGY SAVING
With the new RIB panels, the APP or APP+ bluetooth cards and the RIB GATE
application installed on your smartphone, you can activate the total shutdown of the
photocells when the gate is stopped.
TECHNICAL FEATURES
- BOXES
surface-mounted in polycarbonate and nylon 6.
- DIMENSIONS
70x70x41 mm
- POWER INPUT
24 Vac/dc (12V Schließen Sie den Jumper auf der Karte).
Make sure the system is compatible with the power provided by the power unit.
- POWER CONSUMPTION
80 mA max.
- TRANSMITTER
modulated with infrared diode
- CAPACITY OF RELAY
1A - 30Vdc
- PROTECTED TO
IP 54
- GREEN LED
TRANSMITTER powered.
- RED LED
RECEIVER aligned.
(N.B. after calibration this turns off in the presence of an obstacle).
- RANGE SELECTION:
15 ÷ 30 m (in good weather conditions)
N.B.: Range may be reduced in the presence of fog, rain, dust, etc.
AUTOMATISMI PER CANCELLI
AUTOMATIC ENTRY SYSTEMS
R.I.B. S.r.l. - Via Matteotti, 162 - 25014 Castenedolo - Brescia - Italy
Tel. ++39.030.2135811 - www.ribind.it - ribind@ribind.it
We declare, on our own responsibility, that
operating devices of FIT SIX comply with the
following standards and Directives:
EN 12453:2017
EN 12978:2003+A1:2009
EN 13241:2016
EN 13849-1:2015 PL»c» CAT2
EN 55014-1:2019
EN 55014-2:2015
EN 60335-1:2016
(Bosio Stefano - Legal Representative)
EN 61000-3-2:2019
EN 61000-3-3:2013+A1:2019
EN 61000-6-1:2019
EN 61000-6-2:2019
EN 61000-6-3:2013
EN 61000-6-4:2020
As is provided by the following Directives:
2014/30/UE
2014/35/UE
Castenedolo, 01-11-2020
