MOUNTING INSTRUCTIONS
Wall-mounting set finger scanner integra
General
Description
Item No.
Dimensions (WxHxD) in mm
Flush-mounting housing:
Front plate:
Material
Flush-mounting housing: Galvanized metal sheet
Front plate:
4
3
6
RJ 45
5
Design
Finger
element
scanner
Front
cover
ekey wall-mounting set FS IN ST
101 302 (101 307 incl. LEDs)
60,50 x 122,50 x 37
96 x 142 x 2
Brushed stainless steel
1
7
2
Flush-mounted
housing
These operating instructions are not subject to updating. You can find the most up to date version of these instructions at
Subject to optical and technical modifications, any liability for misprints excluded.
Mounting
Before you proceed with mounting, make a recess in the masonry, at a
minimum height of 155 cm (height to the lower edge of the flush-
mounting housing).
a. Fix the flush-mounting housing (1) into the masonry using the 4
retaining brackets (2).
b. Fit the finger scanner
c. Proceed with the wiring
d. Place the finger scanner
flush-mounting housing (1).
e. Once you have found the ideal position, fix the finger scanner
using the screws. Both self-locking parts turn outwards and both the
finger scanner
flush-mounting housing (1).
f. Snap the design element
and then on the bottom side of the finger scanner (see figure (7)).
LED connection (only for part no. 101 301)
When connecting the LEDs, be sure to pay attention to the
BEWARE: LEDs are not suitable for AC operation!
www.ekey.net.
ID 20/665/0/596: Version 5, 2018-05-09
Media Center ID: 4027
(3)
into the front plate (4).
(5)
(see wiring diagram).
(3)
with the front plate
(3)
and the front plate
(4)
are thus fixed to the
(6)
into place, first on the top side
Supply voltage:12-14 VDC
On-state current: 10-20 mA
polarity!
