G8-TEL
Telephone interface card for connecting the Intercom Server GE 800 to an analogue PABX subscriber or
to a standard telephone line.
Connection diagram
Connection telephone line
A B
NC NC NC NC
G8A-TEL
NC = not connected
Extent of supply
• Telephone interface
• Installation board G8A-TEL
• Connection cable (3 m/9.8 ft)
• Short reference
Safety warnings
• The G8-TEL shall be installed or replaced by trained and qualified personnel only.
• For installation of the G8-TEL into a GE 800, the connection board G8A-TEL has to be used.
• The installation board G8A-TEL may only be used with a G8-TEL.
• Cards may be exchanged only with voltage switched off.
• Before using the G8-TEL, ensure all cables are connected correctly and not damaged.
• Do not make any unauthorised modifications to the G8-TEL.
• In the event of problems, contact your equipment supplier in the first instance.
Observe the precautions for handling of electrostatic sensitive devices.
Disposal and recycling
Equipment with this symbol shall not be disposed of together with household or commercial
waste.
The directive 2012/19/EU on waste electrical and electronical equipment (WEEE) is applicable
in the European Union member states.
Manufacturer's reference
This device complies with the European directives listed below by fulfilling corresponding
standards:
• Electromagnetic compatibility (directive 2014/30/EU)
• The restriction of the use of certain hazardous substances in electrical and electronic
equipment (directive 2011/65/EU)
For technical specifications, see the respective manual.
For the latest software and documentation, visit: www.commend.com
Keep this description in safe custody.
Type: D-BZ-G8-TEL, Version: 2.0/0317 Commend International GmbH, Saalachstraße 51, A-5020 Salzburg – www.commend.com
Installation
The G8-TEL can be inserted into the slots "1" to "14" .
Installation reference for Germany
The G8-TEL may be connected to an analogue
telephone connection only as single dialling
equipment. For this, use a F-coded TAE plug.
