PNI GB1200 Benutzerhandbuch Seite 3

Plug in a power socket
Plug in a power socket
Notes:
• We recommend that you place the mesh device in a less crowded area, such as
on a shelf or in a central area.
• The farthest mesh device may have a purple LED, a flashing red LED, and a
3
Router Mode
Solid purple led: Start up.
Solid blue led: The Internet is connected.
Blue led ashes: TouchLink starts up,
users can connect to the device without password
(search "MeshGo_Touch" then connect directly);
the newly added device is being paired.
Red led ashes: The device is disconnected.
Connect to Internet port of the device
Extender Mode
Solid purple led: Start up.
Solid blue led: The connection between
mesh devices is good.
Solid red led: The connection between
mesh devices is week, please put the device
somwhere less crowded, or shorten the distance
between the devices.
Blue led ashes: "TouchLink" or
"Mesh Pair" is being activated
Red led ashes: The device is disconnected.
Connect
the modem
to the Internet
User manual
