Converting the rechargeable battery
The rechargeable battery can be converted between:
-
45.115.02 (4.0 Ah / 72 Wh) --> low stress for the battery resulting in a total service life which is about three times longer
-
45.115.03 (6.0 Ah / 108 Wh) --> long running time per battery charge
The rechargeable battery is supplied in 45.115.02 (4.0 Ah / 72 Wh).
These articles can be converted between each other by entering a code (9-digit chronological key sequence).
To do so, proceed as follows:
Important! Read the instructions in full before you start to convert the rechargeable battery!
1.
Press the button for the battery charge level indicator (A) and hold it pressed for about 6 seconds until the battery
starts counting from 1 to 9 in the display (B). Then let go.
2.
- To convert from 45.115.02 (4.0 Ah / 72 Wh) to 45.115.03 (6.0 Ah / 108 Wh), press the button (A) briefl y when the
fi gure 6 is shown. After this, counting continues as normal up to 9. (Code: 0 0 0 0 0 1 0 0 0)
- To switch over from 45.115.03 (6.0 Ah / 108 Wh) to 45.115.02 (4.0 Ah / 72 Wh), press the button (A) briefl y when the
fi gure 4 is shown. After this, counting continues as normal up to 9. (Code: 0 0 0 1 0 0 0 0 0)
3.
Once the sequence has counted up to 9 in the display (B), the capacity of the converted article will be shown as
"6Ah" or "4Ah" for about 2 seconds.
The rechargeable battery has now been converted.
Important! Conversion only takes place if the button (A) is pressed precisely when the digit 4 or 6 appears. This
operation is necessary in order to prevent unintended conversion. After conversion, the rechargeable battery
is a diff erent device with a diff erent article number. The new specifi cations label can be obtained by going to
www.isc-gmbh.info.
Attention! For the lithium-ion battery to be allowed to be sent or transported in accordance with special provisi-
on 188, it must be converted to 45.115.02 (4.0 Ah / 72 Wh)! Defective lithium-ion batteries are not allowed to be
sent normally! In this connection, contact iSC GmbH, Eschenstrasse 6, 94405 Landau/Isar (Germany),
www.isc-gmbh.info
Battery charge level indicator
Press the battery charge level indicator button (A) briefl y. The display (B) for the battery charge level indicator initially dis-
plays the charge status in % and then the current set charge level consecutively for 2 seconds each.
Important! The charge level adjusts accordingly after conversion to 45.115.02 (4.0 Ah / 72 Wh) or 45.115.03 (6.0 Ah /
108 Wh) and may vary from that of the previous article. If, for example, the rechargeable battery in 45.115.02 (4.0 Ah / 72
Wh) had a charge level of 100% and it is converted to 45.115.03 (6.0 Ah / 108 Wh), the charge level then will be well below
100%. You therefore then need to charge up the battery before doing anything else.
Error codes
Code
F01
The battery is too hot (e.g. due to direct
sunlight)
F02
The battery is too cold
F03
The battery is overloaded.
F04
The battery is defective
F05
The battery is partially fully discharged
A
B
Cause
GB
The corresponding safety information / instructions can be
found in the safety information and original operating instruc-
tions issued for the equipment. Warning! Read all the safety
information and instructions carefully!
Description
A - Button for battery charge level indicator
B - Display for battery charge level indicator
Store it at room temperature (approx. 20° C) for one
day.
Store it at room temperature (approx. 20° C) for one
day.
Remove the battery from the equipment and try it
again. No change: see F01
A defective battery is not allowed to be used any more.
Recharge the battery.
- 3 -
Remedy
