2. NAME OF SPARE PARTS
Pan supports
Burner
Ceramic Ignitor
IMPORTANT
This appliance shall only be used with a butane gas cartridge certified to EN417 or UL147B IT MAY BE
HAZARDOUS TO ATTEMPT TO FIT OTHER TYPE OF GAS CONTAINERS.
*REMOVE ANY TRANSIT PROTECTION MATERIAL.
3. FITTING THE GAS CARTRIDGE
1. Make sure the cartridge locking lever is in the "UNLOCK "position if not the
gas cartridge can not be installed.
Make sure the control knob is turned all the way clockwise to the "OFF"
position. (Fig.1)
2. Open the gas cartridge cover and insert the cartridge so that the valve tab is
aligned with the slot in the cartridge rim. (Fig.2)
Check that the seals between the appliance and the gas cartridge are in place
and in good condition before connecting the gas cartridge.
DO NOT use this appliance if it has damaged or worn seals.
DO NOT use this appliance if it is leaking, damaged or dose not operate
properly.
3. Push down on the cartridge lever to the "FUEL LOCK" position. (Fig.3)
NOTE: if there is a leak from your appliance (smell of gas) and you can not stop
the gas flow, remove the appliance to a well-ventilated location away from any
ignitions source. Check for leaks using soapy water.
Do not try to detect leaks using a flame.
CAUTION: when connecting or disconnecting the gas cartridge, be sure that no external sources of
ignition are present.
WARNING
THE OPENINGS AT THE BASE OF THE BURNER PROVIDE AIR FOR COMBUSTION, THEY
SHOULD NEVER BE OBSTRUCTED. IF THE FLAME BECOMES SIGNIFICANTLY ORANGE
CHECK THESE OPENINGS FOR A BLOCKAGE.
IF THE APPLIANCE CAN NOT BE ADJUSTED TO PERFORM CORRECTLY IT SHOULD NOT BE
USED UNTIL SERVICED OR REPAIRED.
About gas cartridge:
Model: 220 grams
Certificate N°: 10/KR/2114-0-REV 5
It may be hazardous to attempt to fit other types of gas containers.
Drip pan
Gas cartridge cover
Control knob
Pressure sensor-lock lever
SLOT
VALVE TAB
4
4. LIGHTING THE STOVE
NOTE: Closed the cartridge cover before lighting. Not closing the cover can cause the cartridge to overheat.
• Turn the control knob counter clockwise until you hear a click indicating that a
spark has been produced.(Fig 4)
• If the stove dose not light, turn the control knob back to OFF position and repeat.
• If after three failed attempts, the stove dose not light, turn the control knob to the
"OFF" position and move the cartridge lever to the "UNLOCK" position.
• Open the cartridge cover and remove
5. TO ADJUST HEAT
Flame can be controlled by turning eh ignition knob between the "INGITION" and "OFF" position.
EXTINGUISHING
1. Turn the ignition knob to "OFF"to shut off fuel supply (Fig.5), Wait until the
flame is fully extinguished before performing the next step.
2. Raise the cartridge lock lever to "UNLOCK" and remove the gas cartridge from
the compartment. (Fig.5)
NOTE: Do not leave the gas cartridge inside the unit when not in use.
6. AFTER USE
(Fig.1)
1. Replace the cap on the gas cartridge after removing it from the unit. Store upright in a cool dry place.
2. Make sure the burner is cool to touch before packing unit away.
7. THE AUTOMATIC SAFETY SHUT-OFF DEVICE ACTIVATION
• When used in high temperature areas, such as the beach during summer or in a hot room, the internal
(Fig.2) pressure of the cartridge may rise to more than 500kPa(normal pressure=200-300kPa) This will activate the
Automatic safety shut-off device inside the regulator.
• Remove the gas cartridge from the compartment.
• If the stove had been in use and was working properly, the butane can should be cold to the touch. If it is
not and feels warm, go back to the "Precautions" on the stove use section and confirm if you are using he
stove correctly.
• Turn the ignition knob to "IGNITION"to release any excess gas inside the regulator. Repeat the 3 steps for
(Fig.3)
inserting the gas cartridge after it has cooled down.
8. MAINTENANCE AND CAUTIONS
• Never leave the stove unattended when hot or when in use.
• Do not modify this appliance
• CAUTION: accessible parts may become very hot.
Keep young children away from the appliance at all times.
• Keep the stove area clear and free of combustible materials, gasoline one other flammable vapors and
liquids.
• Do not obstruct the flow of ventilation and air around he appliance.
• It is recommended to service yearly if the injector gets blocked, it should be replace by an authorised
person.
• Keep your stove clean using a soft brush to clean the burner head.
• Use a soft cloth to dean greasy parts of the stove with a soap and water.
• Keep the igniter and the burner head gap free from debris for easy lighting.
• Clean stove frequently to avoid grease build up and as necessary.
• Burner flame should be blue with hint if yellow tip.
(Fig.4)
5
(Fig.4)
(Fig.5)
(Fig.5)
