Operating instructions
Solar wild animal repeller
Item no. 710016
Use in accordance with manufacturer's instructions
The product is intended to be used to scare away animals by means of an ultrasonic sound that is not audible
to the human ear. The product is power by NiMH rechargeable batteries, which are charged via a solar cell
integrated in the device.
An inbuilt PIR motion detector detects heat changes in the detection range (e.g. if an animal moves in the
detection range) and activates an ultrasonic sound.
Any use other than described above may damage the product, there may also be other dangers. Observe all
the safety instructions in these operating instructions.
Read these operating instructions completely and carefully as they contain very important information about
installation, operation and handling. Observe all safety instructions!
Package Contents
• Wild animal repeller incl. NiMH rechargeable batteries
• Ground spike
• Wall bracket and mounting material
• Operating Instructions
Safety Instructions
The warranty will be void in the event of damage caused by failure to observe these safety
instructions! We do not assume liability for any resulting damage.
We do not assume any liability for material and personal damage caused by improper
use or non-compliance with the safety instructions. In such cases the warranty will be
null and void.
• The unauthorised conversion and/or modification of the product is inadmissible because of
safety and approval reasons. Never open/dismantle the product (except as described in this
manual for inserting/changing the rechargeable batteries).
• The product is not a toy and must be kept out of the reach of children. The product contains
small parts and rechargeable batteries. Position the product so it is out of the reach of children.
• The product is suitable for operation in unprotected outdoor areas. However, never dip the
product in or under water as this may destroy it!
• Do not leave packing materials unattended. They may become dangerous playthings for
children.
• Handle the product with care, it can be damaged by impacts, blows, or accidental drops, even
from a low height.
General Notes about Batteries
• Keep rechargeable batteries out of the reach of children.
• Please observe the correct polarity (plus/+ and minus/-) when inserting the rechargeable batteries.
• Do not leave the batteries lying around in the open; there is a risk of them being swallowed by children or
pets. If swallowed, consult a doctor immediately, it could be fatal!
• Make sure that the rechargeable batteries are not short-circuited, opened, taken apart or thrown into a fire.
There is a risk of fire and explosion!
• Old or flat rechargeable batteries can leak liquid chemicals that may damage the device. Therefore, if you
will not be using the device for a while (e.g. during storage) remove the rechargeable batteries.
• If your skin comes into contact with leaking or damaged batteries, you may suffer burns. For this reason
you should use suitable protective gloves.
• Only use rechargeable batteries of the correct size and the recommended type.
• Always replace the complete set of rechargeable batteries.
• Only insert rechargeable batteries into the wild animal repeller. If you insert normal batteries, there is a
risk of fire and explosion!
Controls
1
Ultrasonic loudspeaker
2
PIR movement sensor
3
LED (lights up when the ultrasonic sound is emitted)
4
Opening for wall-mounting
5
Sliding switch for operating mode
6
Wall bracket with joint
7
Battery compartment for 4 rechargeable batteries of the type AA/Mignon, 1.2 V, NiMH
8
Opening for the enclosed ground spike
PIR sensor features
The PIR motion detector responds to temperature changes within the detection range, e.g. if a person, an
animal or a car with a different temperature to the detection area enters the detection area.
To ensure optimal motion detection, the motion detector must be placed so that the object to be detected
does not approach the motion detector directly but passes from left to right or vice versa. Bear this in mind
when you choose a suitable location for installation.
The range for detecting motion is determined by several factors:
• The motion detector's mounting height
• The temperature difference between the moving object and the background (ambient)
• The size of the object
• The distance of the object from the motion detector
• Direction and speed of the movement
• Ambient temperature
Getting Started
• Open the battery compartment (7). If the four NiMH rechargeable batteries are enclosed separately, insert
the batteries paying attention to the correct polarity (observe positive/+ and negative/-). Otherwise, check
whether the manufacturer has inserted a protection strip between the rechargeable batteries and metal
contacts and if that is the case, remove it. Close the battery compartment again.
• Select a suitable installation location. The installation location should be selected so the solar cell is not
in the shade (e.g. under trees or the like), otherwise the rechargeable batteries cannot be charged suf-
ficiently.
The wild animal repeller can be either installed in a suitable location using the enclosed ground spike or
you can use the adjustable wall bracket.
When the product is started up for the first time, the rechargeable batteries are empty. Switch
off the repeller (switch position "AUS"). First, leave the product in the sun for one or two days, to
charge the rechargeable batteries (the charging process for the NiMH batteries takes place in
any switch position!).
• Align the PIR motion detector (2) with the direction you wish to monitor. The detection angle of the PIR
sensor is approx. 100° and the detection range is approx. 5 m.
• Move the function switch (5) to the required position:
"AUS"
The wild animal repeller is switched off (the NiMH rechargeable batteries are still
charged via the integrated solar cell!).
"PIR EIN"
The PIR motion sensor is active. If it detects a temperature change in the detection
area, the ultrasonic sound is activated for a few seconds (or as long as the motion
continues in the detection area). At the same time, the integrated LED (3) lights up.
If the ultrasonic sound is deactivated, the LED also goes out; after an interval of 2
seconds, the animal repeller is operational again.
"Ohne PIR EIN"
The animal repeller emits a continuous tone, the LED (3) is lit.
Please note:
Normally, the ultrasonic sound (25 kHz +/-10%) is not audible to the human ear. However, for
many animals this tone is very loud and irritating.
Thus, place the wild animal repeller so any animal can leave the area surrounding the animal
repeller without any problem. Never place the animal repeller next to small cages, dog kennels
or similar!
Maintenance and Cleaning
Apart from the the occasional battery change, the product is maintenance-free. It is necessary to replace the
batteries if, despite prolonged charging in the sun, the rechargeable batteries only have a short battery life.
Repair or maintenance work must be carried out by a specialist.
Clean the product with a soft, clean, dry cloth.
Never use aggressive cleaning agents or chemical solutions since these might damage the surface of the
casing or impair the operation.
Disposal
a) In general
Dispose of an unserviceable product in accordance with the relevant statutory regulations.
Remove any rechargeable batteries inserted and dispose of them separately from the product.
b) Disposal of used batteries/rechargeable batteries
As the end user, you are required by law (Battery Ordinance) to return all used batteries/rechargeable batte-
ries; disposal of them in the household waste is prohibited!
Contaminated batteries/rechargeable batteries are labelled with these symbols to indicate that
disposal in the domestic waste is forbidden. The symbols for the relevant heavy metals are: Cd
= Cadmium, Hg = Mercury, Pb = Lead.
You can dispose of your used batteries/rechargeable batteries free of charge at your community's collection
point or any place where batteries/rechargeable batteries are sold!
You thus fulfil the legal requirements and make your contribution to protecting the environment!
Technical Data
Power supply ........................................ 4 rechargeable batteries of type AA/Mignon, NiMH, 1.2 V, 850 mAh
Battery life ............................................. Position "PIR EIN" approx. 10 days
.............................................................. Switch position "Ohne PIR EIN": approx. 5 days
.............................................................. (with fully charged batteries)
Ultrasound frequency ........................... ca. 25 kHz +/- 10%
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in
electronic data processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
This publication represent the technical status at the time of printing.
Copyright 2016 by Conrad Electronic SE.
710016_V2_0616_01_VTP_m_en
