Assembly
• Use the supplied double-sided adhesive pads to attach the lighting system POWER-
MULTILight Wireless to any clean and adherent substrate.
• Use the supplied transparent stickers as an intermediate layer on less adherent or
rough surfaces. The transparent stickers ensure a perfect surface for attaching the
double-sided adhesive pads.
• The adhesive pads are reusable, meaning you can simply remove POWER-MULTI-
Lights for recharging. Protect the adhesive surfaces against dust and water.
• Instead of the double-sided adhesive pads, you can also use hook and loop tape.
(Multiplex hook and loop tape sections 25x60mm pair 5x., item no. # 683112)

Operating modes

Switch on and set by pressing button on side of lamp.
• Mode A: Double flash
• Mode B: Single flash
• Mode C: Slow flash

Specifications

Dimensions per lamp: 48mm x 15mm x 14mm
Weight per lamp: 5.8 g
Type of battery: 1S LiPo, 85mAh
Safety: Integrated undervoltage protection
Luminous period: Depending on selected mode:
red, approx. 1h 30min; green, approx. 1h 45min; white,
approx. 2h 15min
Warranty / Disclaimer
MULTIPLEX Modellsport GmbH & Co.KG accepts no liability for loss, damage or costs which arise due incorrect
use and operation, or which are in any way connected with such use. To the maximum extent permitted by
law, the obligation of MULTIPLEX Modellsport GmbH & Co.KG to compensate for damage, for whatever legal
reason, is limited to the invoice value of the merchandise of MULTIPLEX Modellsport GmbH & Co.KG directly
involved in the incident causing the damage. This does not apply if MULTIPLEX Modellsport GmbH & Co.KG is
obliged to accept unlimited liability in accordance with mandatory law for intent or gross negligence.
We guarantee our products in accordance with the current legal requirements. In guarantee cases, please
contact the retailer from which you bought your product.
Malfunctions caused by the following are excluded from the guarantee:
• Incorrect operation
• Maintenance that is either incorrect, not performed or not performed on time, or not performed by an authorized entity
• Incorrect connections
• Use of non-MULTIPLEX/HiTEC-original accessories
• Modifications/repairs which were not carried out by MULTIPLEX or a MULTIPLEX service center
• Deliberate or accidental damage
• Faults resulting from normal wear and tear
• Operation outside of the technical specifications or in conjunction with components from other manufacturers
Disposal
This symbol means that it is essential to dispose of electrical and electronic equipment separately
from the domestic refuse when it reaches the end of its useful life. Take your unwanted equip-
ment to your local communal collection point or recycling centre. This applies to all countries of
the European Union, and to other European countries with separate waste collection systems.
CE Conformity Declaration
This product is compliant with directive 2011/65/EU
Errors and omissions excepted.
Technical modifications reserved.
