GB
FEATURES
MPS-CO2 is a gas detector only to be used with monitoring units
SPxx or MPUx.
FUNCTION
The sensor continuously measures the gas concentration and gives
an analog signal to the monitoring unit, when the signal reaches the
alarm thresholds an alarm will be activated.
Note! Alarm levels are always set in the monitoring unit.
MAINTENANCE, ANNUAL CHECK
Testing the system is recommended to be done twice a year using
a service tool. Connect service tool to test terminal (1).
INSTALLATION/POSITIONING
When mounting the transmitter consider density of target gas and
air movements in the room or area. See examples in previous
page. Connect the transmitter according to the wiring diagram.
IS MPS-CO2 1506 (SV_ENG_TY).doc
MPS-CO2
MODELS
MPS-CO2-[range]:
Range:
TECHNICAL DATA - COMMON
Sensor type:
Response time (T90): <10 seconds
Output signal:
Calibration:
Sensor lifetime:
Operating temperature: -40
Operating humidity:
Housing:
Power consumption:
Sensor cable:
Cable gland:
Dimensions (LxHxD):
Specifications subject to change.
4
USED FOR
Carbon Dioxide
0 - 2000ppm (option)
0 - 5000ppm (option)
0 - 10000ppm (standard)
NDIR
1..5V DC
Automatic Baseline Correction
>15 year (replacement recommended every
10th year or when the unit no longer
indicates any gas)
o
o
C..+50
C
10-90 % Rh (non condensing)
PC polycarbonate (IP67)
max. 2,5 W
2
3 x 0,75 mm
up to 50 meters
2
3 x 1,5 mm
up to 100 meters
1 x M16
80 x 82 x 56 mm
