Kappa D408KIT Bauanleitung

ATTACCHI SPECIFICI PER - SPECIFIC FITTING KIT FOR
KIT DE MONTAGE SPECIFIQUE POUR - SPEZIFISCHER MONTAGEKIT FÜR
ANCLAJE ESPECÍFICO PARA
KAWASAKI KLR 650 2008
ISTRUZIONI DI MONTAGGIO - MOUNTING INSTRUCTIONS
INSTRUCTIONS DE MONTAGE - BAUANLEITUNG - INSTRUCCIONES DE MONTAJE
1
3
1 2
VITE TBEI M6x16mm VITE TEF M6x35mm
SUPPORTO
SCREW SCREW
SUPPORT
VIS VIS
SUPPORT
SCHRAUBE SCHRAUBE
HALTERUNG
TORNILLO TORNILLO
SOPORTE
Q.TY n.2
Q.TY n.4
(Dx-Sx)
7
COMPONENTI ORIGINALI
ORIGINAL PARTS
PARTIES ORIGINALES
ORIGINAL BAUTEILE
COMPONENTES ORIGINALES
Q.TY n.-
1
A
3 4
MOUSSE
Ø22x3mm Ø8mm Z1954
RONDELLA Ø6mm
RUBBER PADS
WASHER Ø6mm
MOUSSE
RONDELLE Ø6mm
SCHUTZGUMMI
SCHEIBE Ø6mm
ESPUMA ADHESIVA
ARANDELA Ø6mm
Q.TY n.2
Q.TY n.4
Q.TY n.8
C
7
6
5 4
© Copyright 041108AR-Rev00, 1/2
5 6
NON INCLUSO
NOT INCLUDED IN THE BOX
PAS INCLUS DANS LA BOITE
NICHT ENTHALTEN IN
DER VERPACKUNG
NO ESTÁ INCLUIDO EN
EL PAQUETE
6
B
7
2
C
