TECHNICAL SPECIFICATIONS

3.1

General specifications

/i
Item
Net weight [kg]
Connections (inlet / outlet) [DN]
3.2

Operating characteristics

/i
Item
Working pressure [bar-g]
Working temperature [°C]
Nominal flow velocity [m/s]
Flange type
Screw thread of the drain valve
3.3 Quality control specifications
NOTE
These are the specifications of the quality control at Spirotech.
3.3.1 Leak test specifications
/i
Item
Test pressure [bar-g]
Test medium
Test time [s]
Approval criterion
3.3.2 Functional test of the automatic air vent
/i
Item
Valve opening test
Valve closing test
3.3.3 Standards
/i
Item
Construction
Quality, safety and environmental
aspects
User manual - 1.0
25 31 45
50 65 80
All types
0 - 10
0 - 110
1.5
PN16 (DIN2633)
Rp1
All types
7 ±1
Air
60
No leakage
All types
Full bore venting
Positive valve closure
All types
Pressure Equipment Directive 2014/68/EU - Sound Engineering Practice
NEN-EN-ISO 9001
NEN-EN-ISO 14001
OHSAS 18001
