TP Toys active fun TP343 Montageanleitung Seite 6

TP343 Castlewood Connection Bridge IN3103 Issue B 04 12:TP343 Castlewood Connection Bridge IN3103 Issue B 04 12 01/05/2012 12:34 Page 6
Siete Pregati di Controllare il Contenuto
Verifique El Contenido
Inhalt - Bitte Überprüfen
Tape
Measure
Socket
13mm
x1
Tower
2
3
x9
MW2056
(455mm)
FA4502
4.5mm x 80mm Woodscrew
x4
FA4513
4.5mm x 30mm
x16
Woodscrew
Contents - Please check
Conteúdos - Por favor verifique
Contenu - Veuillez Vérifier
Power
Screwdriver
Wrench
A
x2
MT0605
(1440mm)
x1
MW2039
(579mm)
FA7184 FA5094
M8 Washer M6 Washer
x36
(25mm o/dia)
x12
Pozi #2
Pozi #3
Pack 1
Fixings - SP 8499
FA8163 FA9023
M8 Dome M6 Dome
Lock Nut Lock Nut
x6 x36
6
Tools - You will need:
Vous aurez besoin de:
Sie benötigen:
Avrete bisngno:
Precisará:
Vai precisar:
13mm
10mm
Spanner Screwdriver
x1
Tower
B
x2
FC1500
x4
PM1006
FA5164 FA5688
M6 x 35mm
M8 x 70mm M8 x 90mm
Bolt Bolt
x36
x2
TP Castlewood Connection Bridge
1
FA6205
Bolt
x4
