Auto Power Link

Auto Power Link automatically turns on the Soundbar when the TV is turned on.
1. Connect the Soundbar and a TV with a digital optical cable.
2. Press the (Source) button on the right side panel or on the remote control, and then select
"D.IN".
3. Press the Left button on the remote control (the blue spot in the illustration to
the right) for 5 seconds to turn Auto Power Link on or off.
• Auto Power Link is set to ON by default.
(To turn off this function, hold the Left button on the remote for 5 seconds.)
• Depending on the connected device, Auto Power Link may not function.
• This function is only available in the "D.IN" mode.

Connecting a TV using an HDMI Cable

1. With the Soundbar and TV turned on, connect the HDMI cable (not supplied) as shown in the figure.
2. "TV ARC" appears in the display window of the Soundbar main unit and the Soundbar plays TV
sound.
• If TV sound is inaudible, press the
of the Soundbar to switch to "D.IN" mode. The screen displays "D.IN" and "TV ARC" in sequence,
and TV sound is played.
Connect to the HDMI IN
(ARC) port of your TV.
HDMI IN
(ARC)
Connect to the HDMI OUT (TV-ARC)
port of the Soundbar main unit.

HDMI Cable
(not supplied)
TV ARC

(Source) button on the remote control or on the right side
ENG - 11
Bottom of the Soundbar
HDMI IN
HDMI OUT
(TV-ARC)
Right Side of the Soundbar
