Specification - Genesis Irid353 Kurzinstallationsanleitung

Specification

• Material SPCC Steel, ABS, Tempered Glass
• Motherboard Support Micro-ATX, mini-ITX
• 3,5" HDD Bays 2
• 2,5" SSD Bays 3
• I/O Connectors USB 3.0 x1, USB 2.0 x2, HD Audio Jack x2
• Expansion Slots 4
• Cooling Support max 5 fans
• Front 120/140 mm x2 (120 mm x1 installed),
120/140/240 mm radiator support
120 mm x1 (installed)
• Rear
120/140 mm x2 (optional), 120/140/240 mm
• Top
Bottom, ATX (max 19 cm)
• PSU Mounting / Standard
163 mm
• Max. CPU Cooler height
375 mm
• Max. GPU Length
27 mm clearance
• Cable Management
Bottom, Top, Front
• Dust Filters
5,8 kg
• Weight
429 x 210 x 393 mm
• Dimensions (LxWxH)
FAN Installation
1. Remove front panel by gently pulling bottom part.
Unscrew side panel
2. Install fans accordingly using screws and according to case plan
3. Suggested fan air ow orientation
Warranty
• 2 years limited manufacturer warranty
Safety information
• For intentional purpose only
• Non-authorized repairs or taking the device to pieces make the warranty
void and may cause the product damage
• Avoid to hit or friction with a hard object, otherwise it will lead to grind
surface or other hardware damage
• Do not use the product in low and high temperatures, in strong
magnetic elds and in the damp or dusty atmosphere
• Do not drop, knock, or shake the device. Rough handling can break it
• Slots and openings in the case are provided for ventilation and should
not be obscured. Blocking the vents can cause overheating of the device
radiator support
2,5" SSD INSTALLATION ON
MOTHERBOARD TRA Y
4. Put AV1 pads onto SS1 screws
5. Next gently screw-in the screws (x4) with applied pads into
SSD bottom screw holes
6. Fix SSD into designated SSD tray holes
Important note: Too tight screwing-in screws with applied
pads might cause drive fastening in designated holes
impossible (pads will get squeezed). Too lose might cause
drive to fall o during transport
2,5" SSD DRIVE INSTALLATION
ON 3,5" HDD Cage
7. Remove HDD cage (pull out)
8. Screw-in SSD on top of HDD cage using MB1 (x4) screws into
SSD bottom holes
9. Install HDD cage (slot-in) with secured drive back into case
3,5" HDD DRIVE INSTALLATION
7. Remove HDD cage (pull out)
8. As rst screw-in HDD drive on top of HDD cage using HD1
(x4) screws into HDD bottom screw holes
9. Second screw-in HDD drive inside HDD cage using HD1 (x4)
screws into HDD side screw holes
FRONT PANEL I/O PORTS INSTALLATION
10. Connect front panel I/O connectors to motherboard according to
motherboard manual
General
• The safe product, conforming to the EU requirements
• The product is made in accordance with RoHS European standard
• The WEEE symbol (the crossed-out wheeled bin) using indicates that this
product in not home waste. Appropriate waste management aids in
avoiding consequences which are harmful for people and environment
and result from dangerous materials used in the device, as well as
improper storage and processing. Segregated household waste
collection aids recycle materials and components of which the device
was made. In order to get detailed information about recycling this
product please contact your retailer or a local authority
