RECEIVING AND UNPACKING

The mod. PINOCCHIO pod coffee machine is packed in a cardboard box, inside an upper and
lower shaped section. Open the box and remove the protective forms in order to take hold of the
bottom of the machine. Rest the machine on a flat surface for the preliminary operations and to
make sure the machine is completely undamaged .
For any doubts, please call any of Spinel service centres.
Forwarders will be held responsible for any breakage or failure related to transport.

POSITIONING AND INSTALLATION

All machine installations and settings must be carried out by authorized
technical staff only.
Spinel S.r.l. is not liable for damages to the machine due to improper
installation of the same, caused by the incompetence or negligence of the
personnel responsible.
Make sure that power voltage and frequency match with the data shown
on the machine's rating plate.
The equipotential protection circuit must be checked at least once a year.
It is necessary to install a proper overcurrent protection device upstream
of the power supply cord.
The following automatic protection switches are recommended:
PINOCCHIO C
PINOCCHIO CV
After checking that the machine is complete, place it on a stable and
perfectly horizontal surface in order to allow enough space for carrying
out all operations easily and safely (insertion of water container, pod
insertion, cleaning and maintenance).
10
Magnetothermic switch
Magnetothermic switch
Tab. 1 - Automatic protection switches
In=10 A Icc=4.5 kA
In=10 A Icc=4.5 kA
2P
2P
