Interlogix SB01 Installation

SB01 Mounting Bracket Installation Sheet
EN DE ES FR IT NL
1A
A
4A
EN: Installation Sheet
Features
The SB01 is a flexible mounting bracket for several UTC Fire & Security
detectors. It has the following features:
• Horizontal adjustment +45°, 0°, -45°.
• Vertical adjustment 0°, -5°.
•
Wall (A) and ceiling (B) mounting.
•
Safety adjustment blocking and mounting inside the detector.
•
Completely enclosed wiring.
•
Throughput wiring is possible.
Mounting
See Figures 1A n to 6A or 1B n to 6B.
Optional
The ST400 tamper switch can be used as a wall and/or ceiling tamper.
UTC Fire & Security Americas Corporation, Inc.
All rights reserved.
2A
5A
1 / 3
3A
6A
Product warnings THESE PRODUCTS ARE INTENDED FOR
and disclaimers SALE TO AND INSTALLATION BY QUALIFIED
PROFESSIONALS. UTC FIRE & SECURITY
CANNOT PROVIDE ANY ASSURANCE THAT
ANY PERSON OR ENTITY BUYING ITS
PRODUCTS, INCLUDING ANY "AUTHORIZED
DEALER" OR "AUTHORIZED RESELLER", IS
PROPERLY TRAINED OR EXPERIENCED TO
CORRECTLY INSTALL FIRE AND SECURITY
RELATED PRODUCTS.
For more information on warranty disclaimers and
product safety information, please check
https://firesecurityproducts.com/policy/product-
warning/ or scan the QR code.
DE: Installationsanleitung
Merkmale
Das SB01 ist eine flexible Montagehalterung für verschiedene UTC Fire
& Security Detektoren und bietet folgende Merkmale:
• Horizontale Einstellmöglichkeit +45°, 0°, -45°.
• Vertikale Einstellmöglichkeit 0°, -5°.
P/N 3059-6A • REV B • ISS 21MAR19
