Owner's Manual
Thank you for purchasing the RK1 Rack Mount Kit.
For details on installation, please refer to the owner's manual of
the product to which you are attaching the RK1.
Included items
• Rack mount hardware (2 pcs.)
• Screws (10 pcs.)
• Owner's manual
Products compatible with the RK1
Products using three screws on each side: 01V96, 01V, 03D,
EMX5000-12, MX12/4, MX12/6
Products using five screws on each side: DM1000
When attaching the RK1 to a product that uses three screws on
each side, install screws in the center hole and in the holes at
each end, as shown below. You will have four screws left over.
Bedienungsanleitung
Vielen Dank, dass Sie sich für einen Rack-Einbausatz RK1 ent-
schieden haben.
Weitere Hinweise zum Einbauverfahren entnehmen Sie bitte der
Bedienungsanleitung des Gerätes, für welches Sie den RK1
gekauft haben.
Lieferumfang
• Hardware für den Rackeinbau (2 Stück)
• Schrauben (10 Stück)
• Bedienungsanleitung
Geräte, für die sich der RK1 eignet
Geräte, für die drei Schrauben pro Seite benötigt werden: 01V96,
01V, 03D, EMX5000-12, MX12/4, MX12/6
Geräte, für die fünf Schrauben pro Seite benötigt werden: DM1000
Beim Anbringen des RK1 an einem Gerät, das drei Schrauben
pro Seite voraussetzt, müssen Sie die Schrauben in der Mitte
sowie der Ober- und Unterseite anbringen (siehe Abbildung). Es
bleiben dann also vier Schrauben übrig.
Mode d'emploi
Nous vous remercions d'avoir opté pour le kit de montage en
rack RK1.
Pour en savoir plus sur l'installation, veuillez consulter le mode
d'emploi de l'appareil auquel vous fixez le RK1.
Articles fournis
• Equerres de montage en rack (2 pcs.)
• Vis (10 pcs.)
• Mode d'emploi
Produits compatibles avec le RK1
Produits utilisant trois vis de chaque côté: 01V96, 01V, 03D,
EMX5000-12, MX12/4, MX12/6
Produits utilisant cinq vis de chaque côté: DM1000
Downloaded from:
http://www.usersmanualguide.com/
RACK MOUNT KIT RK1
E
(as of February 2003)
G
(Stand: Februar 2003)
F
(en février 2003)
Lorsque vous fixez le RK1 à un appareil se servant de trois vis de
chaque côté, insérez les vis dans l'orifice central et aux deux
extrémités. Il vous restera quatre vis superflues.
Manual de instrucciones
Gracias por adquirir el kit de montaje en rack RK1.
Para información sobre su instalación, consulte el manual de
instrucciones del producto en el que instalará el RK1.
Elementos incluidos
• Hardware de montaje en rack (2 piezas)
• Tornillos (10 piezas)
• Manual de instrucciones
Productos compatibles con el RK1
Productos que utilizan tres tornillos en cada lado: 01V96, 01V,
03D, EMX5000-12, MX12/4, MX12/6
Productos que utilizan cinco tornillos en cada lado: DM1000
Al instalar el RK1 en un producto que utiliza tres tornillos en
cada lado, instale los tornillos en el orificio central y en los orifi-
cios de cada extremo, tal como se muestra a continuación. Le
sobrarán cuatro tornillos.
取扱説明書
このたびは、 ラックマウントキット R K 1 をお買い上げいただ
きまして、まことにありがとうございます。
取付方法に ついては、取り付ける機器の取扱説明書をご参照
ください。
同梱品
・ラックマウント金具
2 個
・ネジ
10 本
・取扱説明書
1 部
■ R K 1 対応機器
片側ネジ 3 本の機器
:
01V 96、01V 、03D 、E M X 5000-12、
M X 12/ 4、M X 12/ 6
片側ネジ 5 本の機器
:
D M 1000
片側にネジ 3 本の機器に取り付ける場合は、下図のように中
央と両端のネジ穴にネジ止めします。ネジは 4 本余ります。
01V96
DM1000
