! These operating instructions are an integral part of
the product. They contain important information and
safety notes, and should be kept in a safe place at all
times. Be sure to pass them on to the new owner if
you ever dispose of the product.
1. I
NTRODUCTION
The brushless "ANTARIS carbotec" power set # 1-00698
offers the advanced pilot an ample amount of excess
power with a 4S LiPo battery - ideal for simple aerobatics
and windy weather.
2. C
/ R
ONTENTS
EPLACEMENT PARTS
• 1 Brushless motor ROXXY C42-50-620kv
• 2 Folding propeller blades 14"x8" CAM-C
• 1 ALU-spinner Ø44 with driver Ø5mm
• 1 O-ring Ø40 UV resistant (44mm spinner)
• 2 bolts and screw for ALU spinner
• 4 Screws M3x10
• 4 flat washers
3. T
. O
YP
PERATIONAL
4S LiPo / MPX 14" x 8" folding prop
Current drain: approx. 52 A
Recommended flight battery / speed controller:
ROXXY EVO LiPo 4-4000 30C with BID-Chip # 31 6629
• 1 Controller ROXXY BL-Control 780 S-BEC # 1-00644
• 1 Controller ROXXYSmart Control 70 MSB (HV)
Do not use the supplied ROXXY C42-50-620kv motor
with more than 4S LiPo when using the recommended
propellers!
4. S
N
AFETY
OTES
The power
set "ANTARIS carbotec"
exclusively for use in modelling applications. Incorrect
use can result in serious personal injury.
• Read the instructions before initiation
• Before every flight, check that the motor and propeller
are securely mounted
• Remove all movable objects from the area around the
propeller before switching the motor on
• Do not allow clothing or any of your extremities to get
close to the spinning propeller
• Never start running the motor in your hand
• Stop the motor immediately if you notice vibration.
Eliminate the cause of the vibration before running it
again; you may need to correct the balance of the
propeller blades
• Make sure the power system is adequately cooled; do
not allow anything to obstruct the free circulation of air
MULTIPLEX Modellsport GmbH & Co.KG • Westliche Gewerbestraße 1 • D-75015 Bretten • www.multiplex-rc.de
Operating Instructions for Power Set "ANTARIS carbotec"
# 1-00696
# 1-00732
# 1-00728
# 1-00816
# 1-00893
D
P
S
ATA OF
OWER
ET
# 31 8579
is
designed
5. A
T
P
SSEMBLING
HE
Install the motor as shown above, referring to the model's
building instructions, then fit the speed controller inside
the fuselage. Ensure that no cables can foul or rub
against the motor's spinning case.
6. I
P
NITIATION OF THE
1. Connect the three wires attached to the speed
controller to the three wires attached to the motor; the
order of connection is unimportant.
2. Locate the UNI connector attached to the speed
controller, and connect it to your receiver.
3. Switch the transmitter on, and check that the throttle
control is at the "OFF" position.
4. Connect the flight battery to the speed controller.
5. Check the direction of rotation of the motor: it should
spin clockwise when viewed from the tail, looking
forward. If this is not the case, disconnect the flight
battery and swap over any two of the three motor wires.
7. ROXXY M
-
OTOR
SPECIFICATION
Type:
#
RPM / V:
Cell count, LiPo:
Shaft Ø:
Diameter:
Length:
Weight:
Mounting:
You can find the operating instructions for ROXXY motors
on the Internet at www.multiplex-rc.de.
S
OWER
ET
S
OWER
ET
ROXXY C42-50-620kv
1-00696
620
4S
5 mm
42,5 mm
43 mm
208 g
Ø25 mm / 4 x M3
Page 1/2
