4. Wiring diagram

Refer to the illustrations on page 3 of this manual.
A 4.2" indoor monitor
B outdoor camera
C PSU
D door lock
E door lock power supply
5. Installation
Refer to the illustrations on page 3 of this manual.
Indoor monitor (I)
• Choose an appropriate installation spot out of direct sunlight. The recommended
installation height is 1.6m.
• Measure the distance between the holes on the mounting bracket and drill holes
accordingly. Place a plug into each hole and fix the bracket using the screws.
• Wire the videophone according to the wiring diagram.
• Fix the indoor monitor firmly onto the bracket.
Outdoor camera (II)
• Choose an appropriate installation spot out of direct sunlight and rain. The recommended
installation height is 1.6m.
• Measure the distance between the holes on the mounting bracket and drill holes
accordingly. Place a plug into each hole and fix the bracket using the screws.
• Wire the outdoor camera according to the wiring diagram.
• Place the intercom unit firmly into the bracket and tighten with the screw.
6. Use
• As soon as a visitor presses the doorbell, the videophone will chime and display the image
picked up from the intercom unit. Press
minutes). The image will be displayed for 30 seconds if the
• The door can be opened by pressing the
door latch has been installed (drive voltage of 12V).
• Press the button to display the image picked up from the intercom unit at any time.
The image will automatically disappear after 10 seconds.
• Press to activate the alarm.
• Adjust the volume, the hue and the brightness no using the corresponding adjustment
sliders.

7. Technical specifications

Length 4-Wire Telephone Cable
Input Signal
Display Time
Calling Only
Monitoring
Picking Up Phone to Talk
Alarm Key
Camera Viewing Angle
Power Supply
Power Consumption
Standby
20.05.2009
CAMSET25
1 video
2 GND
3 +12V power
4 audio
5 lock A
6 lock B
to talk (the image will be displayed for 2
unlocking button provided that an optional
15m (incl.)
1Vpp @ 75Ω
30 sec
10 sec
2 min
10 sec
92°
15VDC/1A (incl.)
< 0.5W
5
yellow
black
red
green
button is not pressed.
