UNILITE SLR-1000 Bedienungsanleitung

SLR-1000 - USB RECHARGEABLE COMPACT WORK LIGHT
FEATURES
High-power 1000 lumen white COB LED
Additional 300 lumen Cree® LED flashlight
Powerful in-built 5200mAh li-ion battery
Glow-in-the-dark strip for extra visibility
180° rotating handle/hook/stand
Strong magnets within the handle
IPX5 water resistant
USB rechargeable - micro-USB cable included
BATTERY - 3.7v 5200mAh Li-ion Rechargeable Battery
DIMENSIONS - folded 55 x 130 x 48mm / extended 55 x 240 x 40mm
WEIGHT - 320g
OPERATION
Floodlight - High > Medium > Low > Off
Flashlight - High > Low > Off
[Press and hold to switch between modes]
[If left in any mode for over 3 seconds, the next press will turn off]
CHARGING
1. Only use a micro-USB 5v cable.
2. Switch product off before charging (do not switch on whilst charging).
3. Lift the charging port cover on the side of the light.
4. Plug the micro-USB end of the cable into the socket.
5. Plug the USB end of the cable into any USB charging port.
6. 6.5 Hours charge time.
**Warranty void if not used with the specified charger**
Power indicator
ADVICE & IMPORTANT INFORMATION!
Do not look directly at the LED. Do not operate in direct sunlight or extreme temperature conditions (below -10⁰C or above 40⁰C). The LED will become hot when switched on; do not touch
and do not place face down on any surface – risk of fire!
Do not use the device if there is any visible damage to the housing, plug or cable. Children under 12 years of age should only use the product under adult supervision.
Do not open, disassemble or attempt to modify the product; this will void the warranty and can be dangerous. Improper use or modification is not covered under the warranty.
Ensure the lens does come into contact with hard/sharp objects; damage to the lens may affect light output.
This product is water resistant to IPX5 – DO NOT SUBMERGE.
To maintain the rechargeable batteries, distributors should recharge the battery every 6 months and users should recharge every 3 months if not using for an extended period. Fully
charge the product before storage. The rechargeable batteries will reach their optimum performance only after several complete charging and discharging cycles. Protect the battery from
heat, intense sunlight, fire, water and moisture – danger of explosion!
If the battery is damaged, fluids can leak out. AVOID contact as this can lead to skin irritation and/or burns. If skin contact happens, rinse thoroughly with water. If irritation persists, seek
medical advice. Also seek immediate medical assistance if battery fluid comes into contact with the eyes.
Do not dispose of this device in normal household waste. It must be disposed of via an authorised disposal centre or at your local waste disposal unit. Please recycle packaging where
possible. Keep these instructions for future reference or for subsequent possessors.
Unilite Limited - The LAB, Winyates Way, Moons Moat North Ind. Est., Redditch, Worcestershire, B98 9FG - UK
T • 00[44] 1527 584 344 F • 00[44] 1527 584 345
USB charge port
on the side
Power & Battery Indicator Lights
Recharging indicator
95%-100%
65%-95%
35%-65%
15%-35%
<15%
E • sales@unilite.co.uk
ANSI FL 1 Standard
FLOOD LIGHT - HIGH
FLOOD LIGHT - MID
FLOOD LIGHT - LOW
FLASHLIGHT - HIGH
FLASHLIGHT - LOW
Floodlight
Glow in the
dark strip
Flashlight
Strong magnets
<15%
15%-35%
35%-65%
65%-95%
95%-100%
W • www.unilite.co.uk
1000
40 M 4 H
Lumens
450
25 M 7 H
Lumens
40
84 H
7 M
Lumens
300
13 H
100 M
Lumens
80
48 H
47 M
Lumens
Flashlight
ON/OFF
Switch
Rotates 180°
Tripod hole
