UNILITE SLR-1450 Bedienungsanleitung

PRODUCT FEATURES
● High power 1450 lumen white COB LED, 6500k
● With 150 lumen 6500k white LED flashlight
● Plus 45 lumen Red and Red flash modes
● Powerful 'LG' 3.7v 5000mAh 21700 Li-ion battery
● Super tough copolymer and aluminium construction
● 180˚ rotating handle/stand with carabiner snap hook
● Strong magnets within the stand
● Glow-in-the-dark strip around reflector for extra visibility
● IPX5 water resistant
● 4 Battery level and charging indicators
● Faster 2A USB-C charging - 3 hour charge time
● 1m high quality USB-C cable included
● Battery can be removed so a convenient spare can be kept at hand
● 21700 li-ion battery has its own USB-C port so is easily charged out
of the lamp and used as a 1A Powerbank
BATTERY - 3.7v 5000mAh 21700 Li-ion
WEIGHT - 288g
DIMENSIONS - folded H 122.5 x W 50.5 x D 50.5mm
extended H 219 x W 50.5 x D 50mm
ADVICE & IMPORTANT INFORMATION!
ƒ Do not look directly at LEDs.
ƒ Do not operate in direct sunlight or extreme temperature conditions (below -20˚C or above
60˚C).
ƒ LEDs can become warm/hot when switched on; DO NOT touch and NEVER place face down
on any surface – risk of fire! Even once the device has been switched off, DO NOT place face
down as the LED/Lens will stay hot/warm for a while.
ƒ Do not use the device if there is any visible damage.
ƒ Do not use the device in the immediate vicinity of flammable materials or gases.
ƒ Take care when charging, check the charging output on the charging source you are using
and DO NOT exceed the stated Max charging input or damage may occur to the battery and
may void the warranty.
ƒ The rechargeable battery will reach full performance after a few complete charging and
discharging cycles.
ƒ To keep the rechargeable battery in optimum condition, it should be recharged every 3-6
months, especially if it is not being used for a long period of time.
ƒ Always fully charge rechargeable batteries before storage and if the rechargeable battery
can be removed, this is advised to avoid battery depletion and avoids the risk of a battery
leaking.
ƒ Always protect lithium batteries from heat, intense sunlight, fire, water and moisture – danger
of explosion!
ƒ If a battery is damaged, fluids can leak out. AVOID contact as this can lead to skin irritation
and/or burns. If skin contact occurs, rinse thoroughly with water. If irritation persists, seek
medical advice. Seek immediate medical assistance if lithium battery fluid comes into contact
with the eyes.
ƒ Children under 12 years of age should only use the product under adult supervision.
ƒ Do not disassemble or attempt to modify the product; this will void the warranty and can be
dangerous. Improper use or modification is not covered under the warranty.
ƒ Take care not to let lenses come into contact with hard/sharp objects, damage/scratches to
lenses will affect light output.
ƒ Do not use the product in the immediate vicinity of flammable materials or gases.
ƒ Before cleaning the product, disconnect the charge cable. Clean with a dry or slightly moist,
clean, lint-free cloth and a mild detergent if required. Do not use cleaners that contain
abrasives or solvents.
ƒ This product is water resistant to IPX5 – DO NOT SUBMERGE. If the product has been
subjected to excessive moisture/water the warranty may be void.
ƒ This product has a 1 year standard warranty (or extended to 2 years once registered online
at WWW.UNILITE.CO.UK/WARRANTY) against manufacturing faults and defects. It does not
cover normal wear and tear, modifications, accidental damage or poor maintenance. Unilite
warranties do not cover disposable battery leaks or the use of incorrect chargers and cables
that can damage rechargeable batteries.
ƒ Do not dispose of this device in normal household waste. It must be disposed of via an
authorised electrical appliance disposal centre or at your local waste disposal unit.
ƒ Please re-use or recycle packaging responsibly.
ƒ Keep these instructions for future reference or for subsequent possessors.
| EU Responsible Contact:
Aspen Pumps France, 353 Allee des Vergers, 76360 Barentin
Tel: +33 (0) 1 78 95 88 82 Email: ventes@aspenpumps.com
English
ANSI FL1 Standard
Floodlight - High
Floodlight - Medium
Floodlight - Low
Flashlight
Red Flood - High
Red Flood - Flashing
OPERATING INSTRUCTIONS
WHITE MODES:- Floodlight High > Floodlight Medium > Floodlight Low
> Flashlight > Off
RED MODES:- High > Flash > Off
[When 'ON' in either WHITE or RED modes, press and HOLD the button
for 3-5 seconds to switch to the other mode]
[If left in any mode for over 3-5 seconds, the next press will turn off]
RECHARGING THE LAMP
1. Lift the charging port cover on the side of the lamp.
2. Only use a 5V USB-C cable (max 2A).
3. Plug the USB-C end of the cable into the charge port.
4. Plug the other end of the cable into a USB charging source (do not
exceed 5V-2A charging input or damage may occur. Please do not
use "Fast Chargers" as this can over-load the battery).
5. The 4x battery indicators on the side of lamp will illuminate and
flash to show charging status. Once fully charged, all the indicators
will illuminate continually.
6. If the battery indicators do not illuminate, remove the cable and
try again.
7. Charge Time: 3 hours
8. Make sure the charge port cover is secured back in place.
(PRODUCT CAN BE USED WHILE RECHARGING)
*Warranty void if not used with the specified cable & max charge input*
RECHARGING THE 21700 BATTERY
You can recharge the 21700 battery outside of the lamp. This enables a spare
to be kept on hand if you require light for an extra long period. Once plugged
in, a Red light will appear on the top of the battery to confirm charging. Once
fully charged it will turn Green.
21700 POWER BANK
The 21700 battery inside the lamp can be removed and used as a 1A
Powerbank via the USB-C port. You will need your own devices charging
cable for this. Plug the USB-C end of your devices charging cable into the
USB-C port. A Blue light will appear on the top of the battery to confirm your
device is being charged.
www.unilite.co.uk
SLR-1450
1450
43M
Lumen
670
30M
Lumen
175
15M
Lumen
150
53M
Lumen
45
--
Lumen
45
--
Lumen
Top White LED
Flashlight
Main
White COB
LED
Battery
Compartment
ON / OFF / Mode Switch
The LAB, Winyates Way, Redditch B98 9FG
Tel: 01527 584344 Email: support@unilite.co.uk
3H
4H
16H
13H
11H
90H
UNILITE |
