8. POWER IGNITIONMODUL
J1
J3
J2
Max. torque
0.35 Nm
J4
The following modes for ignition functions are selectable by jumper:
J4 Jumper attached=On
A
B
C
D
Mode
Off
Off
Off
Off
P0
On
Off
Off
Off
P1
Off
On
Off
Off
P2
On
On
Off
Off
P3
Off
Off
On
Off
P4
On
Off
On
Off
P5
Off
On
On
Off
P6
On
On
On
Off
P7
Off
Off
Off
On
P8
On
Off
Off
On
P9
Off
On
Off
On
P10
On
On
Off
On
P11
Off
Off
On
On
P12
On
Off
On
On
P13
Off
On
On
On
P14
Spectra GmbH & Co. KG
vertrieb@spectra.de
F1
J5
Off-delay at all rails on
5V
Hard-off
SB
PSU mode
5 sec + 1 min auto-latch
1 min
5 sec + 1 min auto-latch
2 h
5 sec + 1 min auto-latch
Never
30 sec + 1 min auto-latch
2 h
30 sec + 1 min auto-latch
Never
30 min
Never
3 h
Never
10 min
1 h
15 min
2 h
1 h
75 min
5 sec + 1 min auto-latch
1 min
5 sec + 1 min auto-latch
10 min
5 sec + 1 min auto-latch
1 min
5 sec + 1 min auto-latch
10 min
Niederlassung Österreich
info@spectra-austria.at
HANDBUCH SPECTRA POWERBOX 12C - SERIE
160.0 mm
145.4 mm
5 V
Hard-off: In case battery voltage falls
SB
below the listed „Switch Off" voltage for 1 minute
or longer, the DC 161 W automatically shuts
down (deep discharge protection):
Mode P1-P10
Switch Off @ 11.0 V – Start @ 12.0 V
Mode P11-P12
Switch Off @ 10.5 V – Start @ 10.8 V
Mode P13-P14
Switch Off @ 10.7 V – Start @ 11.3 V
Switch Off @: Separation of the application
from 5V
during the Hard-off time when the
SB
voltage drops below the specified value for
1 minute or longer.
Start @: Required voltage to (re-) start system.
AutoLatch: With this function the PC's power
is not disconnected within the first 60 seconds
to guarantee a secure start and shutdown of
the PC, e.g. during a very short ignition.
CN1
10
20
J6
CN2
4
2
1
11
80.2 mm
J1 input +
Flat plug 6.3 x 0.8 mm or equal
J3 Ignition/Start (not in mode P0)
Flat plug 6.3 x 0.8 mm or equal
J2 input –
Flat plug 6.3 x 0.8 mm or equal
J4 Jumper block (incl. Jumper)
J5 Remote ON/OFF
for motor vehicle amplifier
JS-6001-02 2 P or equal
J6 Mainboard ON/OFF
JS-6001-02 2 P or equal
F1 Fuse 20 A
Output connector
CN1
ATX, SATA, HD, FD power connections
CN2
P4/EPS power connection
For more information, please see the
„Application Note" at www.bicker.de
Spectra (Schweiz) AG
info@spectra.ch
Tolerance: ±0.5 mm
7.3 mm
3
1
13
