Getting Connected:
The transmitter is easily connected. The system only works properly by using
Beatfoxx SilentClub headphones and accessories. Please follow these steps:
1. Attach the antenna to the transmitter. (Arrow #1)
2. Connect a cable from the audio output of the music source to the RCA audio
input located on the transmitter. (See diagram)
3. Connect a microphone to the 1/8" input on the transmitter to be mixed with
the audio signal. (See diagram)
4. Select the transmission power level.
5. Select the channel from one of the available frequencies to broadcast on via
the channel select switch. (Arrow #2)
6. Power your "SilentClub"-headset receiver(s) ON and select the appropriate
channel with the TUNE button.
7. Adjust the headset receiver volume to a comfortable listening level.
Attention: Listening on too high volume can damage your hearing easily!
With this setup, audio signals that are fed into the transmitter will be broadcasted
wirelessly to all headset receivers of SilentClub Series tuned to the same channel
and within its operational range.
