Meaning of display icons

①
"#####", photo count
When the device is in photo mode, the number of photos reminding (memory available) will be displayed.
②
"00:00:00", reminding recording Time
When the device is in video mode, and not recording, the reminding recording time will be displayed (hrs/min/sec).
When the device is in video mode, and recording, the elapsed recording time will be displayed (hrs/min/sec).
③
« NO CARD »
When MicroSD card is not inserted in the device, the message «NO CARD » will be displayed.
④
" ", record indicator
When the device is in recording video mode, the red point flashes.
⑤
"1.7x", zoom factor
The digital zoom magnification factor will be displayed in 0,1x increments, from 1,0x until 5,0x.
⑥
"IR2", Infrared level
IR3=Normal; IR2=Low ; IR1=Very low; IR0=OFF; No icon=DAY Mode.
⑦
Battery level
This icon indicate the reminding battery power level.
⑧
Image Brightness (frame rate)
OFF=day/30 fps ; no icon displayed.
LOW=night/25 fps;
MED=night/15 fps;
HIGH=night/8 fps;
