Handheld Microphone - VONYX WM62 Gebrauchsanleitung

FRONT- AND BACKPANEL
1. Volume
2. Display
3. Up function / Set channel data
4. Down function / Set channel data or press long to apply IR function
5. Antenna
6. Infrared sensor
7. Power On/Off
8. Power input via micro USB connector
9. XLR connector for output signal to mixer
10. 6.3mm ¼ Jack for output signal to mixer
Models:
179.262 : WM62 UHF Microphone System with 2x handheld microphone
179.264 : WM62B UHF Microphone System with 2x bodypack

HANDHELD MICROPHONE

1. Grille, protects the cartridge and help reducing the breath sounds and wind noise.
2. Display
3. IR Learn sensor
4. Power ON/OFF
5. Up / Down Channel selection
6. Battery compartment - 2xAA 1.5V
Attention: If the handheld microphone are not used for a longer period, please remove the
batteries to prevent damage in case of battery leakage!
3
