Power cord included in the scope of delivery
ELECTRIC SHOCK
Wet conditions and moisture may cause short circuits. The following must be ensured:
GB
- 8 -
7.5

Installation filter disc, flash lamp and chip card

A maintenance flap is located on the side of the unit to allow the removal of the flash lamp and the respective chip card
for the lamp.
To open the maintenance flap, loosen the self captivating plug locking screws, lift the maintenance flap and remove it.
Insert filter disc into notch.
19) Filter disc
20) Chip card
The flash lamp is placed directly above filter disc and gets connected via a 3 pole ceramic socket which is secured
against wrong poling.
CAUTION
Insert flash lamp with a little expenditure of energy up to the stop!
Risk of damage to the flash lamp and ceramic socket when not plugged correctly.
If flash lamp is incorrect or incomplete plugged, it would not be possible to close the maintenance flap completely!
Downloaded from www.Manualslib.com
Use in Europe
Use in USA / Japan
The unit may only be operated in dry rooms / areas.
manuals search engine
Voltage: 230 V
Voltage USA: 115 V / Voltage Japan: 100 V
19 20
